How to Adjust the Brakes on a Yard Machine Riding Mower
How to Adjust the Brakes on a Yard Machine Riding Mower. The MTD Yard Machine riding mower does not move very fast, therefore the brake is not designed for emergency stops. The machine is equipped with a single disc brake mounted on the right of the transaxle, with both the clutch and brake are activated by a single clutch-brake pedal. Depressing...
The MTD Yard Machine riding mower does not move very fast, therefore the brake is not designed for emergency stops. The machine is equipped with a single disc brake mounted on the right of the transaxle, with both the clutch and brake are activated by a single clutch-brake pedal. Depressing the pedal half way disengages the engine, while depressing it fully engages the disc brake. To set the parking brake, pull out the parking brake knob while fully depressing the pedal. However, periodic examination and adjustment of the brake is essential since the brake pads are subjected to wear during normal operation,
Things You'll Need
Notepaper
Box wrench
Park the machine on level ground and turn the engine off.
Depress the clutch-brake pedal fully and pull up on the parking brake knob mounted on the console to lock the parking brake.
Block all wheels to prevent the machine from moving during adjustment.
Locate the brake spring leading from the clutch-brake lever to the disc brake actuating lever mounted on the right of the transaxle.
Insert a piece of note paper between the brake spring coils; if you can slide the paper between the coils, the brake is properly adjusted. If not, go to the next step.
Tighten the lock nut situated at the fulcrum point above the spring on the brake actuating lever, using a box-end wrench, until the paper can slip between the coils.
Release the parking brake and remove the wheel blocks. Place the gear lever in the neutral position and depress the clutch-brake pedal fully.
Have an assistant push the machine forward. If the machine moves, repeat the above steps until proper brake adjustment is achieved and your assistant cannot move the machine while the clutch-brake pedal is fully depressed.
